Our Sugatsune Stainless Steel Clip On Hinge is ideal for environments exposed to moisture due to the high corrosion resistance.

Opening to 100°, this hinge gives you full access when the door is open, while ensuring a tight fit to the frame face when the door is closed.

The products Specification sheet can be found at the bottom of this page, please read for installation guidance. Please click here to view our Help Guides & Advice page.





Specifications



• Material: Stainless Steel (SUS 304)
• Overlay: 17 - 19mm
• Opening Angle: 100 degrees
• Door Thickness: 15 - 22mm
• Cup Diameter: 35mm
• Cup Drilling Depth: 11mm
• Self Closing: Yes
• Adjustment: 3 way
• Sugatsune Code: 100-C46/19





Compatible Mounting Plates

Sugatsune Stainless Steel Cruciform Mounting Plate



Recommended Screws

Stainless Steel Pozi Countersunk Screw 4 x 16mm (8 x 5/8")
